Liffey 22kW

BPE’s Liffey 22kW is designed for

domestic and commercial applications

BPE Faster Charging

FASTER CHARGING

Personal EV Charging points like BPE’s Liffey 22kW are faster at charging batteries from empty to full when compared to using a standard 7.4kW charger

BPE Better Life Cycle

SAFETY FEATURES

The BPE Liffey 22kW EV charger offers integrated Type A RCD and PEN Fault detection devices; this eliminates the need for expensive external RCDs and earth rods



BPE Value

VALUE

After the initial costs of installation, the cost of running your Electric Vehicle is cheaper. Dependent on the car and electricity tariff, a full charge can cost as little as £5

BPE Liffey 22 kw EV Charger

Liffey 22kW

The BPE Liffey 22kW is an intelligent, universally connectable 22kW dual port fast EVC. The Liffey 22kW is a 3-Phase AC EV charger. A plethora of data points are displayed on a large LCD screen which is customisable to your preferred language. The EV Charger has the ability to receive and download software updates remotely. The Liffey 22kW comes with built in safety features to avoid overcurrent and guarantee the charging location is safe for both vehicle, building and user.

Liffey 22 kW Main Benefits:

  • Dual Fast 22kW charger
  • Two Type 2 socket or tethered cables
  • Smart: OCPP 1.6
  • LCD screen
  • Integrated 30 mA AC type A RCD with separate 6 mA DC detection device

Liffey 22kW Specification

Power Input

Input Rating: 400Vac± 10%, 50/60Hz Three-Phase
Wiring: L1+L2+L3+N+PE
Internal RCD: 30mA AC Type A RCD and separate 6mA DC detection device

Power Output

Output Power: 2 x 22kW max
Output Current: 2 x 32A max
Charging Interface: Type 2 tethered or socket only

User Interface & Control

Status Indicator: RGB LED
Isolator Switch: External integrated isolator switch
Card Reader: ISO/IEC 14443 A/B Mifare RFID reader

Communication

Network Interface: 4G, Bluetooth & Wi-Fi
Charging Protocol: OCPP 1.6

Environmental

Operating Temperature: -30°C – 55°C
Storing Temperature: -40°C – 70°C
Humidity: 0% – 95% no condensation
Altitude: <3000m

Mechanical

Ingress Protection: IP55
Impact Protection Rating: IKIO (Housing), IK8 (Screen)
Cooling: Passive cooling
Dimensions (WxHxD): 395 x 504 x 197 mm
Weight: 17.5kg
Charging Cable Length: 5m
Installation: Wall-mounted, Pole-mounted

Certification

CE

Warranty

5 years

Power Input

Input Rating: 400Vac± 10%, 50/60Hz Three-Phase
Wiring: L1+L2+L3+N+PE
Internal RCD: 30mA AC Type A RCD and separate 6mA DC detection device

Power Output

Output Power: 2 x 22kW max
Output Current: 2 x 32A max
Charging Interface: Type 2 tethered or socket only

User Interface & Control

Status Indicator: RGB LED
Isolator Switch: External integrated isolator switch
Card Reader: ISO/IEC 14443 A/B Mifare RFID reader

Communication

Network Interface: 4G, Bluetooth & Wi-Fi
Charging Protocol: OCPP 1.6

Environmental

Operating Temperature: -30°C – 55°C
Storing Temperature: -40°C – 70°C
Humidity: 0% – 95% no condensation
Altitude: <3000m

Mechanical

Ingress Protection: IP55
Impact Protection Rating: IKIO (Housing), IK8 (Screen)
Cooling: Passive cooling
Dimensions (WxHxD): 395 x 504 x 197 mm
Weight: 17.5kg
Charging Cable Length: 5m
Installation: Wall-mounted, Pole-mounted

Certification

CE

Warranty

5 years
